- Compatible EN81-20
- Assigned and programmable outputs
- Door opening leveling
- Adjustment of parking floor inside the car
- 3 m/s speed support
- Exit to next floor
- Ability to work up to 4 groups of lifts
- Call redirection in group operation
- 16 standard stops, up to 32 floors
- Call buttons and call lamps need only one shared wire.
- Programming with password protection, PUK code protection against unauthorized using.
- Last 20 errors including information of floor can be traced on LCD screen.
- In stand-by mode the operation time of the lift after the last maintenance (as day and hour) is screened on LCD screen.
- Adjustable maintenance time, warning when it is the maintenance time on LCD screen,
- With built-in panel terminals, simple and fault free installation, saving in time and control panel terminals.
- Over-load function
- Short-circuit protected display outputs which can be adjusted to every floor.
- Gray/Binary code converter board
- Outputs for direction arrows, Out Of Service signal and busy signal’ via SA relay, signal common input for these outputs.
- Adjustable park floor and duration of parking time.
- Pulse bi-stable switches for car position sensing
- The car position information with 4 encoder inputs
- Optional, when the electric power is on again, moving the car to the first floor.
- Warning signal on LCD screen when the door is open or when no stop signal more than the adjusted time.
- Adjustable car lamp time, lock wait time, wait at floor time, max high speed time and max low speed time.
- Door opening signal (AUTO) selection type of working related to direction arrows,
- Function of manual movement at low speed by using program buttons.
- Selection of the first target floor on outside displays when each floor passing,
- At revision mode selection of the movement to limit sw!tches and exact floor level.
- Selection of the floor with the full automatic door for the lifts which has only one door is full automatic
- Electronic controlling of phases, phase order and PTC (Motor temperature) shown faults about these controls via LCD screen,
